Solar-Powered · SOLAR-SOLO-S
SOLAR-SOLO-S
SOLAR-SOLO-S is an AC charging solution providing 7 kW for one vehicle, used with SOLAR7. It features integrated 5-metre Type 2 cable connections, an IP65-rated metal enclosure and ground-anchored installation.
SOLAR-SOLO-S Technical Specifications
| Charging power | 1×7 kW; total / peak 7 kW |
|---|---|
| Power supply | 240 V, single-phase |
| Maximum current | 1×32 A |
| Connection | 1×integrated Type 2 cable, 5 m |
| Connectivity | Wi-Fi + BLE; optional RFID |
| Meter | Optional |
| Dimensions | 50×150×30 cm |
| Installation | Ground-anchored |
| Ingress protection | IP65 |
| Grid connection | No external grid connection required |
| Compatible solar system | SOLAR7 |
| Residual current protection | RCD Type A + 6 mA DC |
| Protection features | Overcurrent, short circuit, overtemperature and overvoltage |
| Enclosure | Electrostatically powder-coated metal |
| Impact resistance | IK08 |
| Operating temperature | -25 °C – +50 °C (typical) |
Actual charging power depends on the vehicle’s AC charging capacity, the power supply and installation conditions. Request a quote for a system and installation suited to your project.
Solar-powered EV charging with SOLAR-SOLO-S
SOLAR-SOLO-S is a solar-powered station specified for 7 kW AC charging from one outlet. The technical specifications list compatibility with one SOLAR7 system. For car parks and business projects, assess the daily energy requirement, available space and solar exposure together.
Connection and system sizing
An integrated 5-metre Type 2 cable provides the vehicle connection. The ground-anchored station offers Wi-Fi and BLE connectivity, with optional RFID and metering. Solar panel peak power is not continuously available throughout the day. Panel placement, shading and system energy management should be determined during project design.
Frequently asked questions
Does SOLAR-SOLO-S deliver the same power at night?
Solar generation varies with the time of day and weather conditions. Operation at night or during low generation depends on the energy storage and supply arrangement selected for the project. Nominal power alone cannot establish uninterrupted operation or a fixed charging time.
How can I request a quote?
Use the Add to quote request button at the top of this page to add this model to your list. Specify your application and required quantity to request a quotation for your project.
