ENSAVE · WALL SERIES
11 kW · Socketed AC charging
The Ensave WALL11-S is an 11 kW wall-mounted electric vehicle charger. Its Type 2 socket is designed for use with an external charging cable.
Designed for a 400 V three-phase supply with a maximum current of 3×16 A. The installation location and electrical infrastructure should be considered together when selecting a charger.
Technical specifications
| Charging power | 11 kW AC |
|---|---|
| Power supply | 400 V, three-phase |
| Maximum current | 3×16 A |
| Connection | Type 2 socket; external user cable |
| Connectivity | Wi-Fi + BLE; optional RFID |
| Meter | Wi-Fi + BLE controlled; optional |
| Dimensions | 25×35×15 cm |
| Installation | Wall or optional pedestal |
| Ingress protection | IP54 standard; optional IP65 |
| Recommended supply cable | At least 5×2.5 mm² |
| Residual current protection | RCD Type A + 6 mA DC |
| Protection features | Overcurrent, short circuit, overtemperature and overvoltage |
| Enclosure | Electrostatically powder-coated metal |
| Impact resistance | IK08 |
| Operating temperature | -25 °C – +50 °C (typical) |
When should you choose a socketed model?
The Type 2 socket suits users who prefer an external cable. Consider cable compatibility and the distance needed to reach the vehicle in the parking space.
Installation and connectivity options
WALL11-S can be wall-mounted or installed on an optional pedestal. The model offers Wi-Fi and BLE connectivity, with RFID available as an option. Standard and optional equipment are confirmed when preparing the quotation.
Frequently asked questions
What power supply does WALL11-S require?
The technical specifications state a 400 V three-phase supply. A qualified installation team should assess the site requirements.
What connection type does it use?
Its Type 2 socket is designed for use with an external charging cable.
How can I request a quote?
Use the Add to quote request button to add this model to your existing list. You can select more products before submitting your request.
